Commercial Passenger Lifts For Homes

This elevator has an exact and effective control system by using the most advanced electronic technology. In addition to this, SUNNY lifts adopt the latest environment-friendly technology in manufacturing, as well as a safety device and signal device.

SUNNY Home Elevator Description

We offer a unique range of Home Elevators. This range requires minimum space and does not require a head room or pit. Moreover, these lifts consume power only while going up and can even work in single phase if required. In case of power failure once can easily come down manually. Owing to the innovative design of the range, the significant cost on pillars and sidewalls can be completely saved.

It displays the outstanding properties in a limited space. It has no machine room. Extremely small top-floor height can match with various old and new residences. Relying on the standard track installation system, the elevator can be installed more quickly and conveniently. In addition, the smooth start and leveling system bring about the rare stable elevator operation.

SUNNY Elevator Specification

Capacity (Kg)/Person		Speed(m/s)	Entrance(mm)	Clear car dimension (mm)	Caroutstide dimension (mm)	Machine room dimension (mm)	Pit depth(mm)	Overhead Height (mm)	Pit reaction load (KN)		Machine room reaction load(KN)		Rated power (KW)
Q	NO.	V	OP	CWXCD	SWXSD	MWXMDXMH	PD	OH	R1	R2	R3	R4	KW
450	6	1	700	1200×1100	1252×1266	1800x1800x2200	1500	4400	50	40	20	8	3
		1.5					1600	4500					4.8
630	8	1	800	1400×1100	1452×1266	2000x1800x2200	1500	4400	68	54	24	10	4.3
		1.5					1600	4500					6.8
800	10	1	800	1400×1350	1452×1516	2000x2050x2200	1500	4400	76	60	28	12	5.4
		1.5					1600	4500					8.6
		1.75					1700	4600					9.6
		2					1800	4700					11
1000	13	1	900	1600×1450	1652×1616	2200x2200x2200	1500	4400	90	72	32	15	6.4
		1.5					1600	4500					10.7
		1.75					1700	4600					11.7
		2					1800	4700					13.4
		2.5					2000	4900					17
		4					3800	5900					27.7
1250	16	1	1000	1800×1550	1852×1716	2400x2300x2200	1500	4400	105	80	36	18	8.5
		1.5					1600	4500					13.5
		1.75					1700	4600					14.8
		2					1800	4700					17
		2.5					2000	4900					22
		4					3800	5900					34.6
1350	18	1	1100	1900×1600	1952×1766	2500x2300x2200	1500	4400	115	90	40	20	9.3
		1.5					1600	4500					14.9
		1.75					1700	4600					16.3
		2					1800	4700					18.7
		2.5					2000	4900					23.4
		4					3800	5900					36.8
1600	21	1	1200	2000×1700	2052×1866	2600x2400x2200	1500	4400	136	105	48	26	11
		1.5					1600	4500					17.5
		1.75					1700	4600					19
		2					1800	4700					22
		2.5					2000	4900					27.5
		4					3800	5900					34.2

About SUNNY Elevator

SUNNY Elevator is always engaged in researching into, developing, manufacturing various building traffic and transport systems such as elevator, escalator, moving walk etc. Through the centurial trials and hardships, SUNNY Elevator never changes its advanced technology.

SUNNY Elevators safely operate in all kinds of high grade buildings in over 100 countries and regions. As time flies, it continues the rigorous and conscientious spirits of the German nation. SUNNY Elevator popular-fixes the most superb elevators and escalators all aver the world and opens the gate of the artistic elevator palace.

FAQ

1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
