Painted Steel Freight Elevator Industrial Grade

Imported light curtains can make the elevator entrance form dense infrared network for sensitive detection of the elevator and out of people or things, high safety performance.

SUNNY Freight Elevator Description

A loading giant that can release more and more cargo pressures for you Shanghai SIGMA freight lift serial fully utilizes advanced and fully computerized control technology. It employs the well-developed VVVF control system of the Shanghai SIGMA elevator. It is simple in structure and convenient in repair and maintenance. It fulfills a qualitative leap in the aspects of signal transmission and running control. It brings about a more stable and reliable system, the lower the noise, the smoother running, and the more accurate leveling. It is easier and easier for goods to enter and exit. In addition, Shanghai SIGMA freight lift serial can offer the microprocessor. The high-speed running capabilities and expansion interface ensure to satisfy the special requirements of broad users. Light curtain protection Several protective light curtains are formed at the entrance of the elevator, which sensibly detects and responses to any objects that intrude into the detecting scope. The safety of humans and cargo is guaranteed. The extremely humane operation It is equipped with a fully automatic collective selective function. It can fulfill operations with driver / without a driver. The operation box specially and additionally sets the”door-shut delay” button in the operation box. Door-shut delay time can be flexibly adjusted at the site according to the requirements. You feel more at ease at loading and unloading the goods out of its humane setting.

SUNNY Freight Elevator Specification

Model	Load	Speed	car size		Door opening Size(mm)		Shafe size(mm)			Machine room size(mm)
Model	kg	m/s	W	D	W	H	W	D	Pit	Over head	W	D
630/0.5	630	0.5	1168	1600	1100	2100	2100	1950	1500	4300	3000	3500
1000/0.5	1000	0.5	1500	1800	1200	2100	2350	2100	1500	4300	3000	3500
1000/0.5(Through car)	1000	0.5	1500	1900	1200	2100	2350	2250	1500	4300	3500	3500
2000/0.5	2000	0.5	2000	2300	1500	2100	2850	2700	1500	4300	3500	4500
2000/0.5(Through car)	2000	0.5	2000	2400	1500	2100	2850	2750	1500	4300	3500	4500
3000/0.5	3000	0.5	2200	2800	1800	2100	3350	3100	1500	4400	4500	5000
3000/0.5(Through car)	3000	0.5	2200	2900	1800	2100	3350	3250	1500	4400	4500	5000
5000/0.5	5000	0.5	2600	3600	2000	2100	3750	3950	1500	4500	4500	5500
5000/0.5(Through car)	5000	0.5	2600	3700	2000	2100	3750	4050	1500	4500	4500	5500

About SUNNY Elevator

SUNNY Elevator is always engaged in researching into, developing, manufacturing various building traffic and transport systems such as elevator, escalator, moving walk etc. Through the centurial trials and hardships, SUNNY Elevator never changes its advanced technology.

SUNNY Elevators safely operate in all kinds of high grade buildings in over 100 countries and regions. As time flies, it continues the rigorous and conscientious spirits of the German nation. SUNNY Elevator popular-fixes the most superb elevators and escalators all aver the world and opens the gate of the artistic elevator palace.

FAQ

1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
